Marine Cast Steel Gate Valve JIS F7363C 5K

Large Image : Marine Cast Steel Gate Valve JIS F7363C 5K

Product Details:

Contact Now

Marine Cast Steel Gate Valve JIS F7363C 5K

Description

Marine Cast Steel Gate Valve JIS F7363C 5K:

Design Standard: JIS F7363C-1996

Test Standard: JIS 7400-1996

Hydraulic Test Pressure: Body- 1.05Mpa, Seat-0.77Mpa

Flange size as per JIS B2220 - 5K

Main Material:

1-Body: Cast Steel (SC450)

2-Disc: Bronze (BC6) or SCS2 (2Cr13)

3-Seat: Bronze (BC6) or SCS2 (2Cr13)

4-tem: Brass (C3771BD) or SUS403

5-Gasket: non-asbestos

6-Packing Gland: Bronze (BC6) or SCS2(2Cr13)

7-Handwheel: FC200 (Cast Iron)

Main Size List(mm):

Size	L	Flange diam. (D)	Pitch (C)	No of Bolt Hole	h	t	H	D2
50	180	130	105	4	15	16	285	125
65	190	155	130	4	15	18	330	140
80	200	180	145	4	19	18	380	160
100	230	200	165	8	19	20	430	180
125	250	235	200	8	19	20	495	200
150	270	265	230	8	19	22	560	224
200	290	320	280	8	23	24	680	280
250	330	385	345	12	23	26	800	355
300	370	430	390	12	23	28	920	400
350	410	480	435	12	25	30	1000	450
400	470	540	495	16	25	30	1100	500
450	500	605	555	16	25	30	1420	560

The description/sizes may be different with goods, please check with us when order.
