JIS F 7301 5K SCS16 Stainless Steel Globe Valves
Marine Stainless Steel Globe Valve or Marine Brass Globe Valve can be called as Marine Stainless Steel/Brass Stop Valve.
Function: Open/Close the pipe system
Design Standard: JIS F7301-1996
Test Standard: JIS F7400-1996
Test Pressure: Body-1.05Mpa, Seat-0.77Mpa
Flange Size as per JIS B2220-5K

*DN15-DN40 with screwed bonnet, DN50-DN65 with bolted bonnet

Main Material:
1-Body: Stainless Steel(SCS16)/SUS316L
2-Disc: Stainless Steel(SCS16)/SUS316L
3-Stem: Stainless Steel(SCS16)/SUS316L
4-Bonnet: Stainless Steel(SCS16)/SUS316L
5-Handwheel: Cast Iron (FC200)

SCS13 SS GATE VALVE

SCS13 SCS16 SS GLOBE VALVE.

SCS13 SCS16 SS GLOBE SDNR VALVE.

SCS13 SCS16 ANGLE VALVE,

SCS13 SCS16 ANGLE SDNR VALVE

Ks JIS 5K Industry Cast Stainless Steel Scs13 Scs16 Ssc 14
