JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450

Large Image : JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450

Product Details:

Brand Name:	OEM
Certification:	ABS,BV,CCS,DNV,KR
Model Number:	JIS F7309 cast iron Globe valve 16K

Contact Now

JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450

Description

Marine Cast Iron Globe Valve JIS F7309 16K

It is suitable for the pipe system with the medium fresh water, air & other gas, oil and steam with the temperature not over 205 centigrade degree.

Design Standard: JIS F7309-1996

Test Standard: JIS 7400-1996

Hydraulic Test Pressure: Body- 3.3Mpa, Seat-2.42Mpa

Flange size as per JIS B2220 - 16K

Main Material:

Body: Cast Iron (FC200)

Bonnet: Cast Iron (FC200)

Packing Gland: Bronze (BC6) or Stainless Steel (2Cr13)

Stem: C3771BD (Brass) or SUS403

Seat: Bronze (BC6) or Stainless Steel (2Cr13, SCS2)

Disc: Bronze (BC6) or Stainless Steel (2Cr13, SCS2)

Gasket: non-asbestos

IMPA 750261 F7309 16K50

IMPA 750262 F7309 16K65

IMPA 750263 F7309 16K80

IMPA 750264 F7309 16K100

IMPA 750265 F7309 16K125

IMPA 750266 F7309 16K150

IMPA 750267 F7309 16K200

Main Size List(mm): Marine Cast Iron Globe Valve JIS F7309 16K

IMPA CODE	DN	L	D	C	No of bolt hole	h	t	H	D2	Weight(kgs)
750261	50	220	155	120	8	19	20	285	160	19.6
750262	65	270	175	140	8	19	22	310	200	28.3
750263	80	300	200	160	8	23	24	340	224	40.4
750264	100	350	225	185	8	23	26	385	250	56.9
750265	125	430	270	225	8	25	26	455	315	89.5
750266	150	500	305	260	12	25	28	510	355	123
750267	200	570	350	305	12	25	30	630	450	188

JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450 0

JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450 1

JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450 2

JIS F7309 MARINE CAST IRON GLOBE VALVE 16K 2" to 14" DN50-DN450 3
