DIN CAST IRON GLOBE VALVE,DIN CAST IRON GLOBE VALVE & GLOBE CHECK VALVE,PN10/PN16 Face to face as per DIN3202 F1

Large Image : DIN CAST IRON GLOBE VALVE,DIN CAST IRON GLOBE VALVE & GLOBE CHECK VALVE,PN10/PN16 Face to face as per DIN3202 F1

Product Details:

Place of Origin:	CHINA
Brand Name:	GMV/OEM
Certification:	ABS.BV.CCS.DNV.
Model Number:	DN15 TO DN300

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Packaging Details:	CARTO/Plywood Box
Delivery Time:	1-5 WORKING DAYS
Payment Terms:	T/T, D/P, D/A, Western Union, L/C
Supply Ability:	1000 PCS/PER WEEK

Contact Now

DIN CAST IRON GLOBE VALVE,DIN CAST IRON GLOBE VALVE & GLOBE CHECK VALVE,PN10/PN16 Face to face as per DIN3202 F1

Description

CAST IRON:	BULE, GREY

DIN CAST IRON GLOBE VALVE & GLOBE CHECK VALVE,PN10/PN16
GREAT MARINE Face to face as per DIN3202 F1
Flange as per DIN2533 PN10/PN16
Medium: Water, Steam, Oil
Working Temperature: ≤ 200℃

IMPA755231 DN15

IMPA755232 DN20

IMPA755233 DN25

IMPA755234 DN32

IMPA755235 DN40

IMPA755236 DN50

IMPA755237 DN65

IMPA755238 DN80

IMPA755239 DN100

IMPA755240 DN125

IMPA755241 DN150

IMPA755243 DN200

IMPA755244 DN250

IMPA755245 DN300

DIN CAST IRON GLOBE VALVE,DIN CAST IRON GLOBE VALVE & GLOBE CHECK VALVE,PN10/PN16 Face to face as per DIN3202 F1 0

No.	Component	Material
1	Body	Cast Iron
2	Seat ring	Staninless steel
3	Disc	Staninless steel
4	Stem	Staninless steel

Size	L	D	D1	D2	b	f	Z-Φd	Do	H
15	130	95	65	47	14	2	4-14	80	170
20	150	105	75	58	16	2	4-14	80	170
25	160	115	85	68	16	2	4-14	100	190
32	180	140	100	78	18	2	4-18	120	210
40	200	150	110	88	18	3	4-18	120	220
50	230	165	125	102	20	3	4-18	140	235
65	290	185	145	122	20	3	4-18	160	275
80	310	200	160	138	22	3	8-18	240	335
100	350	220	180	158	24	3	8-18	240	375
125	400	250	210	188	26	3	8-18	280	425
150	480	285	240	212	26	3	8-23	320	490
200	600	340	295	268	30	3	12-23	360	620

DIN CAST IRON GLOBE VALVE,DIN CAST IRON GLOBE VALVE & GLOBE CHECK VALVE,PN10/PN16 Face to face as per DIN3202 F1 2

DIN CAST IRON GLOBE VALVE,DIN CAST IRON GLOBE VALVE & GLOBE CHECK VALVE,PN10/PN16 Face to face as per DIN3202 F1 3
